Software 227 / Piaggio bikes / handsfree SPARK

Memory device is Renesas R5F10BLGK 64 pin QFP package.
For reading and writing of DATA FLASH area, you can use UPA-USB-S or XPROG-box, download connection diagram.
Expected file size is 4096 bytes.
Use original handsfree key with NCF29A1M transponder or PCF7939MA transponder.
Written key or transponder is ready and programmed to start the bike.
Vehicles equipped with this unit:
Piaggio: Beverly
