TN014 - Key programming for 2020+ Toyota vehicles (BA HT-AES)

Requirements	AMS	I18

The TN014 license expands the key programming capabilities of the ABRITES software for the latest generations Toyota vehicles, equipped with Tokai Rika Smart System with BA type HT-AES keys. Even the latest models 2022/2023 are supported! (see the list below)

Functionalities:

• Spare key programming
• ALL KEYS LOST

Supported models:

• Yaris 2020+ (XP210) BA HT-AES
• Yaris Cross 2021+ (XP210) BA HT-AES
• Corolla Facelift 2022+ (E210) BA HT-AES
• Corolla Cross Facelift 2022+ (XG10) BA HT-AES
• Aygo X 2022+
• Yaris GR 2021+
• Corolla GR 2022+

Including the models, already supported in the TN011 legacy license:

• Corolla 2018+ AA HT-AES
• Camry 2018+ A9 DST-AES
• Highlander 2018+ AA DST-AES
• Mirai 2020+ AA DST-AES

No additional subscriptions (dealer access) are required to complete the key programming procedure.

This solution covers said models, regardless of the market on which they are offered - all versions of the models are supported (US, European, UK, Asia). Smart system reset is NOT needed, nor a connection to Toyota servers.

Depending on the transponder type in the vehicle, either a HT-AES (TA64) or a DST-AES (TA68) emulator will be required. CB012 will also be required for internal CAN-BUS connection to the vehicle.
An AVDI interface with a valid AMS subscription, a ZN002 or ZN003 PROTAG V2 Programmer are required to use this license.
